Threading Tools

TAP M10 X 1.5 D6 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .286 SHANK DIAMETER 1-1/4" THREAD LENGTH .286 SQUARE SIZE 7/16" SQUARE LENGTH 2-15/16" OVERALL LENGTH

TAP M12 X 1.75 D6 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .275 SHANK DIAMETER 1-21/32" THREAD LENGTH .275 SQUARE SIZE 7/16" SQUARE LENGTH 3-3/8" OVERALL LENGTH

TAP 4-40 HAND PLUG H1 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 9/16" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 1-7/8" OVERALL LENGTH

TAP 4-40 HAND BOTTOM H1 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 9/16" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 1-7/8" OVERALL LENGTH

TAP 5-40 HAND PLUG H1 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 5/8" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 1-15/16" OVERALL LENGTH

TAP 5-40 HAND BOTTOM H1 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 5/8" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 1-15/16" OVERALL LENGTH

TAP 6-32 HAND PLUG H2 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 11/16" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 2" OVERALL LENGTH

TAP 6-32 HAND BOTTOM H2 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 11/16" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 2" OVERALL LENGTH

TAP 6-40 HAND PLUG H1 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 11/16" THREAD LENGTH .110 SQUARE SIZE 1/4" SQUARE LENGTH 2" OVERALL LENGTH

TAP 6-40 HAND BOTTOM H1 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .141 SHANK DIAMETER 11/16" THREAD LENGTH .110 SQUARE SIZE 1/4" SQUARE LENGTH 2" OVERALL LENGTH

TAP 8-32 HAND PLUG H2 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .168 SHANK DIAMETER 3/4" THREAD LENGTH .131 SQUARE SIZE 1/4" SQUARE LENGTH 2-1/8" OVERALL LENGTH

TAP 8-32 HAND BOTTOM H2 3 FLUTE HIGH SPEED STEEL SCREW THREAD INSERT SERIES 783 .168 SHANK DIAMETER 3/4" THREAD LENGTH .131 SQUARE SIZE 1/4" SQUARE LENGTH 2-1/8" OVERALL LENGTH
