Threading Tools

TAP 9/16-18 H3 4 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .429 SHANK DIAMETER 1-21/32" THREAD LENGTH .322 SQUARE SIZE 1/2" SQUARE LENGTH 3-19/32" OVERALL LENGTH

TAP 5/8-11 H3 4 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .480 SHANK DIAMETER 1-13/16" THREAD LENGTH .360 SQUARE SIZE 9/16" SQUARE LENGTH 3-13/16" OVERALL LENGTH

TAP 5/8-18 H3 4 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .480 SHANK DIAMETER 1-13/16" THREAD LENGTH .360 SQUARE SIZE 9/16" SQUARE LENGTH 3-13/16" OVERALL LENGTH

TAP 3/4-10 H3 4 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .590 SHANK DIAMETER 2" THREAD LENGTH .442 SQUARE SIZE 11/16" SQUARE LENGTH 4-1/4" OVERALL LENGTH

TAP 3/4-16 H3 4 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .590 SHANK DIAMETER 2" THREAD LENGTH .442 SQUARE SIZE 11/16" SQUARE LENGTH 4-1/4" OVERALL LENGTH

TAP M3 X 0.5 D3 2 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .141 SHANK DIAMETER 5/8" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 1-15/16" OVERALL LENGTH

TAP M3.5 X 0.6 D4 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .141 SHANK DIAMETER 11/16" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 2" OVERALL LENGTH

TAP M4 X 0.7 D4 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .168 SHANK DIAMETER 3/4" THREAD LENGTH .131 SQUARE SIZE 1/4" SQUARE LENGTH 2-1/8" OVERALL LENGTH

TAP M4.5 X 0.75 D4 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .194 SHANK DIAMETER 7/8" THREAD LENGTH .152 SQUARE SIZE 1/4" SQUARE LENGTH 2-3/8" OVERALL LENGTH

TAP M5 X 0.8 D4 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .194 SHANK DIAMETER 7/8" THREAD LENGTH .152 SQUARE SIZE 1/4" SQUARE LENGTH 2-3/8" OVERALL LENGTH

TAP M6 X 1.0 D5 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .255 SHANK DIAMETER 1" THREAD LENGTH .191 SQUARE SIZE 5/16" SQUARE LENGTH 2-1/2" OVERALL LENGTH

TAP M8 X 1.25 D5 3 FLUTE 52 HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER SERIES 763 .238 SHANK DIAMETER 1-1/8" THREAD LENGTH .238 SQUARE SIZE 3/8" SQUARE LENGTH 2-23/32" OVERALL LENGTH
