Taps

TAP 12-28 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .220 SHANK DIAMETER 15/16" THREAD LENGTH .165 SQUARE SIZE 9/32" SQUARE LENGTH 2-3/8" OVERALL LENGTH

TAP 1/4-20 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .255 SHANK DIAMETER 1" THREAD LENGTH .191 SQUARE SIZE 5/16" SQUARE LENGTH 2-1/2" OVERALL LENGTH

TAP 1/4-28 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .255 SHANK DIAMETER 1" THREAD LENGTH .191 SQUARE SIZE 5/16" SQUARE LENGTH 2-1/2" OVERALL LENGTH

TAP 5/16-18 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .318 SHANK DIAMETER 1-1/8" THREAD LENGTH .238 SQUARE SIZE 3/8" SQUARE LENGTH 2-23/32" OVERALL LENGTH

TAP 5/16-24 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .318 SHANK DIAMETER 1-1/8" THREAD LENGTH .238 SQUARE SIZE 3/8" SQUARE LENGTH 2-23/32" OVERALL LENGTH

TAP 3/8-16 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .381 SHANK DIAMETER 1-1/4" THREAD LENGTH .286 SQUARE SIZE 7/16" SQUARE LENGTH 2-15/16" OVERALL LENGTH

TAP 3/8-24 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .381 SHANK DIAMETER 1-1/4" THREAD LENGTH .286 SQUARE SIZE 7/16" SQUARE LENGTH 2-15/16" OVERALL LENGTH

TAP 7/16-14 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .323 SHANK DIAMETER 1-7/16" THREAD LENGTH .242 SQUARE SIZE 13/32" SQUARE LENGTH 3-5/32" OVERALL LENGTH

TAP 7/16-20 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .323 SHANK DIAMETER 1-7/16" THREAD LENGTH .242 SQUARE SIZE 13/32" SQUARE LENGTH 3-5/32" OVERALL LENGTH

TAP 1/2-13 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .367 SHANK DIAMETER 1-21/32" THREAD LENGTH .275 SQUARE SIZE 7/16" SQUARE LENGTH 3-3/8" OVERALL LENGTH

TAP 1/2-20 H3 3 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .367 SHANK DIAMETER 1-21/32" THREAD LENGTH .275 SQUARE SIZE 7/16" SQUARE LENGTH 3-3/8" OVERALL LENGTH

TAP 9/16-12 H3 4 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .429 SHANK DIAMETER 1-21/32" THREAD LENGTH .322 SQUARE SIZE 1/2" SQUARE LENGTH 3-19/32" OVERALL LENGTH
