Threading Tools

TAP 3/8-24 COMBINATION DRILL H3 2 FLUTE HIGH SPEED STEEL SERIES 707 .381 SHANK DIAMETER 13/16" DRILL LENGTH 0.3395 DRILL SIZE 1-1/16" THREAD LENGTH 3-3/8" OVERALL LENGTH 7/16" SQUARE LENGTH

TAP 7/16-14 COMBINATION DRILL H3 2 FLUTE HIGH SPEED STEEL SERIES 707 .323 SHANK DIAMETER 1" DRILL LENGTH 0.3770 DRILL SIZE 1-1/4" THREAD LENGTH 3-3/4" OVERALL LENGTH 13/32" SQUARE LENGTH

TAP 7/16-20 COMBINATION DRILL H3 2 FLUTE HIGH SPEED STEEL SERIES 707 .323 SHANK DIAMETER 1" DRILL LENGTH 0.3955 DRILL SIZE 1-1/4" THREAD LENGTH 3-3/4" OVERALL LENGTH 13/32" SQUARE LENGTH

TAP 1/2-13 COMBINATION DRILL H3 2 FLUTE HIGH SPEED STEEL SERIES 707 .367 SHANK DIAMETER 1-1/8" DRILL LENGTH 0.4350 DRILL SIZE 1-3/8" THREAD LENGTH 4-1/16" OVERALL LENGTH 7/16" SQUARE LENGTH

TAP 1/2-20 COMBINATION DRILL H3 2 FLUTE HIGH SPEED STEEL SERIES 707 .367 SHANK DIAMETER 1-1/8" DRILL LENGTH 0.4580 DRILL SIZE 1-3/8" THREAD LENGTH 4-1/16" OVERALL LENGTH 7/16" SQUARE LENGTH

TAP M4 X 0.7 COMBINATION DRILL MD4 2 FLUTEHIGH SPEED STEEL SERIES 708 .168 SHANK DIAMETER 0.1340 DRILL SIZE 1/2" THREAD LENGTH 3/8 " DRILL LENGTH 2-1/8" OVERALL LENGTH 1/4" SQUARE LENGTH

TAP M5 X 0.8 COMBINATION DRILL MD4 2 FLUTE HIGH SPEED STEEL SERIES 708 .194 SHANK DIAMETER 0.1700 DRILL SIZE 5/8" THREAD LENGTH 13/32 " DRILL LENGTH 2-3/8" OVERALL LENGTH 1/4" SQUARE LENGTH

TAP M6 X 1.0 COMBINATION DRILL MD5 2 FLUTE HIGH SPEED STEEL SERIES 708 .255 SHANK DIAMETER 0.2030 DRILL SIZE 25/32" THREAD LENGTH 17/32 " DRILL LENGTH 2-1/2" OVERALL LENGTH 5/16" SQUARE LENGTH

TAP M8 X 1.25 COMBINATION DRILL MD6 2 FLUTE HIGH SPEED STEEL SERIES 708 .318 SHANK DIAMETER 0.2730 DRILL SIZE 15/16" THREAD LENGTH 11/16 " DRILL LENGTH 2-27/32" OVERALL LENGTH 3/8" SQUARE LENGTH

TAP M10 X 1.50 COMBINATION DRILL MD6 2 FLUTE HIGH SPEED STEEL SERIES 708 .381 SHANK DIAMETER 0.3440 DRILL SIZE 0.69" THREAD LENGTH 13/16 " DRILL LENGTH 3.38" OVERALL LENGTH 7/16" SQUARE LENGTH

TAP M12 X 1.75 COMBINATION DRILL MD6 2 FLUTE HIGH SPEED STEEL SERIES 708 .367 SHANK DIAMETER 0.4140 DRILL SIZE 1-3/8" THREAD LENGTH 1-1/8 " DRILL LENGTH 4-1/16" OVERALL LENGTH 7/16" SQUARE LENGTH

TAP 3-48 H2 2 FLUTE HIGH SPEED STEEL HI SPIRAL FLUTE 52 DEGREE HELIX MODIFIED BOTTOM 2 - 2-1/2 CHAMFER GROUND THREAD SERIES 761 .141 SHANK DIAMETER 1/2" THREAD LENGTH .110 SQUARE SIZE 3/16" SQUARE LENGTH 1-13/16" OVERALL LENGTH
